Understanding the Need for Text Conversion in AutoCAD
When working with AutoCAD, it’s common to encounter situations where text is segmented into multiple single lines instead of being organized as a single multiline text entity. This separation can make editing and formatting more cumbersome. Combining these individual lines into a single multiline text object simplifies management and enhances the overall presentation of your drawings.
Steps to Convert Single Line Text to Multiline Text
Step 1: Ensure Express Tools are Installed
Before proceeding, verify that the Express Tools are installed in your AutoCAD setup. This feature is essential as it provides access to commands necessary for the conversion process. You can check for the Express Tools by navigating to the Tools menu.
Step 2: Access the TXT2MTXT Command
The conversion process utilizes the TXT2MTXT command. This command can be quickly found by:
- Typing
TXT2MTXTdirectly into the command line and pressing Enter. - Alternatively, if you prefer a graphical interface, you can follow this path:
- Click on the Ribbon menu.
- Navigate to the Insert tab.
- Locate the Import panel where the TXT2MTXT command is available.
Step 3: Selecting Text Objects
Once the command is initiated, you’ll be prompted to select the text objects you wish to convert. Carefully click on each single line text item you want to combine into a multiline text block. As you select them, ensure that they are the correct lines intended for merging.
Step 4: Finalizing the Conversion
After all the desired text objects have been selected, press Enter to complete the selection. AutoCAD will process the command and automatically convert the selected single line text into a single multiline text object.
Step 5: Review and Edit
It’s a good practice to review the newly created multiline text entity. You can adjust the formatting, font, and other properties as needed to ensure it meets your design requirements. Double-click on the multiline text block to open the text editor for any changes.
Product Compatibility
The TXT2MTXT command is available across various editions of the AutoCAD software, including AutoCAD and AutoCAD LT. It is compatible with versions ranging from 2008 up to the latest release, AutoCAD 2025. This ensures broad accessibility for users across different projects.
Frequently Asked Questions
1. Can I use TXT2MTXT in AutoCAD LT?
Yes, the TXT2MTXT command is available in AutoCAD LT as long as the Express Tools are installed.
2. What should I do if I can’t find the TXT2MTXT command?
If the command isn’t available, make sure that Express Tools are properly installed. You can do this through the installation setup or consult the AutoCAD help resources.
3. Are there any limits on the number of text lines I can convert at once?
There are no specific limits imposed by AutoCAD itself for converting multiple lines at once, but performance may vary based on your system specifications and the complexity of the drawing.
